Product features:

• 1. Low insert loss.

• 2. High mechanical reliability.

• 3. Environmental Stability.

• 4. Good uniformity.

• 5. Can be connectorized with many different connector types.

• 6. High channel counts.

• 7. Wide wavelength range.

Applications:

• 1. FTTX (FTTP, FTTH, FTTN, FTTC).

• 2. LAN, WAN & Metro.

• 3. CATV.

• 4. Test & measurement.

Specifications of 1XN splitters:

Split ratio	1x2	1x4	1x8	1x16	1x32	1x64
Insert loss	Max 3.8dB	Max 7.2dB	Max 10.5dB	Max 13.8dB	Max 17.1dB	Max 20.1dB
Uniformity	Max 0.6dB	Max 0.6dB	Max 1.0dB	Max 1.1dB	Max 1.5dB	Max 1.8dB
Return loss	Without connector≥55dB, With UPC connector≥50dB, With APC connector ≥60dB
PDL	Max 0.3dB	Max 0.3dB	Max 0.3dB	Max 0.3dB	Max 0.4dB	Max 0.4dB
WDL	Max 0.5dB	Max 0.5dB	Max 0.5dB	Max 0.5dB	Max 0.8dB	Max 0.8dB
Directivity	≥55dB
Operating Wavelength	1260 ~ 1650nm
Operating temp	-40 ~ +85°C
Storage temp	-40 ~ +85°C
Fiber type	G657A or Customized

Specifications of 2XN splitters:

Split ratio	2x2	2x4	2x8	2x16	2x32	2x64
Insert loss	Max 4.2dB	Max 7.5dB	Max 11.0dB	Max 14.3dB	Max 17.5dB	Max 21.5dB
Uniformity	Max 1.2dB	Max 1.5dB	Max 1.6dB	Max 1.8dB	Max 2.3dB	Max 2.5dB
Return loss	Without connector≥55dB, With UPC connector≥50dB, With APC connector ≥60dB
PDL	Max 0.3dB	Max 0.3dB	Max 0.3dB	Max 0.3dB	Max 0.4dB	Max 0.4dB
WDL	Max 0.5dB	Max 0.5dB	Max 0.5dB	Max 0.5dB	Max 0.8dB	Max 0.8dB
Directivity	≥55dB
Operating Wavelength	1260 ~ 1650nm
Operating temp	-40 ~ +85°C
Storage temp	-40 ~ +85°C
Fiber type	G657A or Customized
