Product features:
1. High strength material.
2. Suitable for indoor and outdoor, wall-mounted, pole, aerial installation.
3. Easy to install and maintenance.
4. Splitter Type: Insert splitter or Cassette Splitter, 1x4, 1x8,1x16,1x32.
5. FC、SC and LC adapters available , modular design, convenient for fixation and maintenance.
6. The splice tray can be taken down and put on the bench for splicing, convenient operation.
Applications:
1. FTTH.
Specifications of Splitter Type Optical Fiber Distribution:
| Splitter Type | Insert Splitter | Cassette Splitter |
| Split ratio | 1x16 | 1x16 |
| 1x32 | 1x32 | |
| Working Environment | Indoor | Indoor |
| Outdoor | Outdoor | |
| Operation Temperature | -25℃～+55℃(Indoor), -40℃～+60℃(Outdoor) | |
| Protection Class | Indoor type IP53, Outdoor type IP55 | |
| Insert Loss | ≤0.3dB | |
| Return Loss | UPC type≥50dB, APC type≥60dB | |
| Dimension H×W×D (mm) | ||
