Product features:

• 1. High reliability & good performance.

• 2. Suitable for connecting many types of cables.

• 3. Easy to use.

• 4. Low insert loss.

• 5. Lower cost of installation.

• 6. Optional Protective cover.

Applications:

• 1. Single-mode and multi-mode fibers.

• 2. Aerial, buried, underground, pedestal.

• 3. FTTX, Metro and Enterprise networks.

• 4. High density substitute for connectors.

Specifications:

Cable type (For mechanical splicer without protect cover)	Fiber (Coating Diameter =250µm or Tight Buffer Diameter=900µm)
	2.0*3.0 mm Drop Cable & 2.0/3.0 mm Indoor Cable
Cable type (For mechanical splicer with protect cover)	2.0*3.0 mm Drop Cable
Insert loss	Max≤0.1dB
Return loss	≥50dB
Operation temperature	-40 ~ +75°C
Tensile strength	≥50 N for type with protect cover, ≥10 N for type without protect cover
